Description
Feel the difference with the Taramps T9000 Chipeo, an amplifier that redefines the standards of musical performance.
Available in 1 or 2 Ohm versions, this fantastic amplifier offers an impressive 9000 WRMS at 12.6 Volts, and can reach an astonishing 11,000 WRMS at 14.4 Volts. With a wide frequency response of 5Hz to 5kHz, it covers sub-bass, bass, mid-bass and mid. Experience much more strength, quality, efficiency and resistance, and take your sound experience to a new level.
Available in 1 or 2 Ohm versions, this fantastic amplifier offers an impressive 9000 WRMS at 12.6 Volts, and can reach an astonishing 11,000 WRMS at 14.4 Volts. With a wide frequency response of 5Hz to 5kHz, it covers sub-bass, bass, mid-bass and mid. Experience much more strength, quality, efficiency and resistance, and take your sound experience to a new level.
TECHNICAL������������������INFORMATION
| 1 OHM VERSION | Nominal Power@12.6VDC 1 Ohm: 9000W RMS 2 Ohms: 5445W RMS Nominal Power@13.8VDC 1 Ohm: 10000W RMS 2 Ohms: 6100W RMS Nominal Power@14.4VDC 1 Ohm: 11000W RMS 2 Ohms: 6710W RMS |
|---|---|
| 2 OHMS VERSION | Nominal Power@12.6VDC 2 Ohms: 9000W RMS 4 Ohms: 5445W Nominal Power@13.8VDC 2 Ohms: 10000W RMS 4 Ohms: 6100W RMS Nominal Power@14.4VDC 2 Ohms: 11000W RMS 4 Ohms: 6710W RMS |
| NUMBER OF CHANNELS | 01 |
| INPUT SENSITIVITY | 220mV ~ 4V RMS |
| SIGNAL TO NOISE RATIO | >90dB |
| FREQUENCY RESPONSE | 5Hz ~ 5KHz (-3dB) |
| EFFICIENCY | 1 Ohm: 79% | 2 Ohms: 84% |
| INPUT IMPEDANCE | 10K Ohms |
| PROTECTION SYSTEM | Short-circuit on output and in relation to GRD, low impedance, high/low voltage and thermal protection |
| MINIMUM SUPPLY VOLTAGE | 9VDC |
| MAXIMUM SUPPLY VOLTAGE | 17VDC |
| CONSUMPTION AT REST | 1 Ohm: 3.70A | 2 Ohms: 1.50A |
| MAXIMUM MUSIC CONSUMPTION | @12,6VDC: 1 Ohm: 450A | 2 Ohms: 423A |
| MAXIMUM CONSUMPTION IN SINUSOIDAL SIGNAL | 1 Ohm: 900A | 2 Ohms: 846A |
| DIMENSIONS (WXHXD) | 8.98" x 2.52" x 17.56" (228 x 64 x 446 mm) |
| WEIGHT | 12.79 lb (5.80 Kg) |
| EAN | 1 Ohm: 7908706600797 2 Ohms: 7908706600780 |
