Description
The Taramps MD 3000.1 in the������������������2-ohms������������������version has been carefully designed with the������������������highest technology, offering������������������high efficiency������������������and performance for various types of car audio systems. This amplifier covers the������������������whole frequency range, that is to say that it is a������������������FULL RANGE������������������module. It is classified as������������������mono������������������and has a channel with a maximum power of������������������3000-Watts RMS. Welcome to Taramps audio world.
Technical Information:
| Operation class | Class D |
|---|---|
| Number of Channels | 01 |
| Maximum power | @ 12.6 VDC - 2 OHMS: 3000W RMS @ 12.6 VDC - 4 OHMS: 1920W RMS |
| Input Sensitivity | 220 mV |
| Signal to Noise Ratio | >90dB |
| Frequency Response | 10Hz ~ 18KHz (-3dB) |
| Crossover high pass (HPF) | 10Hz ~ 90Hz (-12dB/8������������������) Variable |
| Crossover low pass (LPF) | 90Hz ~ 18KHz (-12dB/8������������������) Variable |
| bass boost | 0 ~ 10dB (50Hz) Freq. Variable (35 ~ 55) |
| Efficiency | 82% |
| Input Impedance | 15K Ohms |
| Output Impedance | 2 OHMS |
| protection system | Short-Circuit to Output, Short on output compared to GND, Low impedance at output, low/high supply voltage and Thermal protection. |
| Min. Supply Voltage | 9VDC |
| Maximum Power Supply Voltage | 16VDC |
| Consumption at rest | 1.50 A |
| Maximum music consumption | 145 A |
| Maximum consumption in sinusoidal signal | 290 A |
| Dimensions (WxHxD) | 8.98" x 2.76" x 8.58" (228 x 70 x 218mm) |
| Weight | 5.5lb (2,5kg) |
| EAN | 7898556844710 |
