Description
The BASS 5K has been carefully designed with the highest technology, with high efficiency and performance for car audio systems aimed at������������������sub-bass and bass responses, in the frequency range of 8Hz to 250Hz. It has a maximum power of������������������5000 Watts in 1 channel of 1 ohm, It features customized adjustments according to the trunk size and the most prominent frequency of each vehicle, through������������������BASS BOOST������������������and the option to choose the central frequency. This amplifier offers much more displacement control, through its������������������SUBSONIC FILTER, volume control and������������������LOW PASS, to get your bass just perfect. Welcome to the audio world by Taramps
Technical Information:
| Operation class | Class D |
|---|---|
| Number of Channels | 01 |
| Maximum power | @ 14.4 VDC - 1 Ohm: 5000 Watts RMS @ 14.4 VDC - 2 Ohms: 3200 Watts RMS |
| Input Sensitivity | 220mV |
| Signal to Noise Ratio | >95dB |
| Frequency Response | 8Hz ~ 250Hz (-3dB) |
| Crossover high pass (HPF) | 8Hz ~ 30Hz (-12dB/8������������������) Variable |
| Crossover low pass (LPF) | 60Hz ~ 250Hz (-12dB/8������������������) Variable |
| bass boost | freq.: 35Hz ~ 60Hz / Boost: 0 ~ +10dB |
| Efficiency | 83% |
| Input Impedance | 15K Ohms |
| Output Impedance | 1 Ohm |
| protection system | Short-Circuit to Output, Short on output compared to GND, Low impedance at output, High/Low supply voltage and Thermal protection |
| Min. Supply Voltage | 9 VDC |
| Maximum Power Supply Voltage | 17 VDC |
| Consumption at rest | 1.20A |
| Maximum music consumption | 209A |
| Maximum consumption in sinusoidal signal | 418A |
| Dimensions (WxHxD) | 9.41" x 2.87" x 12.87" (239 x 73 x 327mm) |
| Weight | 11lb (5kg) |
| EAN | 7898556844765 |
